Every mill test certificate for structural and line pipe steel reports a carbon equivalent value, but the number on its own doesn't tell a procurement engineer what to do with it. Ceq exists to answer one practical question: does this material need preheating before it's welded, and if so, roughly how much? This guide covers how Ceq is calculated, what the resulting value means for weldability, and how it maps to preheat practice — as a reference for evaluating incoming certificates, not a substitute for your project's qualified welding procedure.

What Is Carbon Equivalent (Ceq) and Why It Matters

Carbon alone determines much of a steel's hardenability, but manganese, chromium, molybdenum, vanadium, nickel, and copper all contribute too. Carbon equivalent converts the combined effect of these elements into a single number expressed in “equivalent carbon content,” so two chemically different steels can be compared on one weldability scale. The higher the Ceq, the harder the heat-affected zone (HAZ) becomes after welding, and the greater the risk of hydrogen-induced cold cracking — the most common weld defect in structural and line pipe steel.

The IIW Carbon Equivalent Formula

The formula most widely referenced across structural steel, API line pipe, and pressure vessel specifications is the International Institute of Welding (IIW) equation:

CEV (IIW) = C + Mn/6 + (Cr + Mo + V)/5 + (Ni + Cu)/15

All element values are the weight percentages reported on the mill test certificate. This formula applies best to carbon and low-alloy steels with carbon content above roughly 0.18%; for lower-carbon, higher-strength line pipe grades, API and EN specifications often reference the Pcm (Ito-Bessyo) formula instead, which weights carbon more heavily and is more representative at low carbon levels. Which formula applies is set by the governing specification — API 5L PSL2, for example, calls for Ceq (IIW) at higher carbon levels and Pcm at lower carbon levels, so the certificate should state which method was used.

Reading the Ceq Value: General Weldability Thresholds

As a general reference — always confirmed against the applicable welding code and project WPS rather than applied as a standalone rule — Ceq (IIW) values are commonly grouped as follows:

These ranges are general guidance only. Actual preheat temperature depends on Ceq, plate or wall thickness, hydrogen level of the welding consumable, restraint, and ambient conditions — all of which are addressed in recognized welding codes such as AWS D1.1 and EN 1011-2. The Ceq value narrows the question; the qualified welding procedure specification (WPS) answers it.

Typical Carbon Equivalent Values by Grade

Ceq varies by grade, thickness, and delivery condition, so the figures below are typical/reference values — always confirmed against the specific heat's mill test certificate:

For the full PSL2 chemistry table this figure is drawn from, including phosphorus, sulfur, and manganese limits, see our API 5L line pipe steel page.

For S355 buyers weighing cross-standard substitutions, note that Ceq is one of the values that can shift between an EN 10025-2 heat and an equivalent ASTM, IS, or JIS grade.

Verifying Ceq on the Mill Test Certificate

Our QA/QC lead, Anup Kurup, checks the Ceq (or Pcm, where applicable) reported on every incoming mill test certificate against the limit set by the governing specification — not just against the general ranges above. Where a certificate reports Ceq close to or above a specification's maximum, that heat is flagged for the customer's engineering review before dispatch, since it directly affects the preheat and welding procedure the fabricator will need to qualify. Every shipment is supplied with EN 10204 3.1 certification, giving the actual measured Ceq — not an assumed or nominal value — for the material received.

FAQ

What is a good carbon equivalent value for structural steel?

There's no single universal “good” value — it depends on the governing specification, section thickness, and welding process. As a general guide, Ceq (IIW) below about 0.35 is readily weldable with minimal preheat, while values above 0.45 typically call for preheat and closer welding procedure control.

Is carbon equivalent the same as Pcm?

No. Both estimate weldability, but Ceq (IIW) weights carbon less heavily and suits carbon content above roughly 0.18%, while Pcm (Ito-Bessyo) weights carbon more heavily and is more accurate for lower-carbon, higher-strength steels such as many API 5L line pipe grades. The governing specification determines which one applies.

Does a low Ceq mean no preheat is ever needed?

Not necessarily. Preheat decisions also depend on section thickness, hydrogen level of the welding consumable, ambient temperature, and joint restraint. A low Ceq reduces the likelihood that preheat is needed, but the qualified WPS — not the Ceq value alone — is what determines the actual requirement.

Where do I find the Ceq value for a specific heat of steel?

It should be reported directly on the mill test certificate (MTC) for that heat, typically alongside the full chemical composition. If a certificate doesn't report Ceq or Pcm and your specification requires it, request a supplementary calculation or a re-issued certificate before the material is accepted.
