Stainless Steels – Specifications, Grades and Properties
The name stainless steel covers a variety of corrosion resistant steels that contain a minimum of 11% Chromium. Changing the Chromium content and adding other elements like Nickel, Molybdenum, Titanium and Niobium changes the mechanical and physical properties of the steel.This results in hundreds of different grades of stainless steel that are covered by a range of national and international standards.
Specifications supplied include precipitation hardening, duplex, super duplex, austenitic and martensitic. Stainless steel grades are supplied in a large range conforming to British, European, American, and International standards.
please contact our experienced sales team who may assist you with your inquiry.
Precipitation Hardening Stainless
High Alloyed Austenitic Stainless
Austenitic Stainless
Martensitic Stainless
Duplex & Super Duplex Stainless
Heat Treatment
Precipitation Hardening Stainless
The main characteristics of precipitation hardening stainless specifications are the combination of the corrosion resistance of an austenitic stainless with the hardenability of a martensitic stainless.
ASTM | Material No | DIN | Firth Vickers |
---|---|---|---|
A564 Grade 630 | 1.4542 | X5CrNiMoCuNb145PH | FV520B |
17/4PH Condition A | 1.4594 | ||
H1150+H1150 |
High Alloyed Austenitic Stainless
High contents of chromium, nickel, molybdenum and nitrogen give high alloyed austenitic stainless steel grades different characteristics to those of standard austenitic specifications. 904L has similar mechanical properties to the more common austenitic grades but has superior resistance to uniform corrosion. UNS S31254 provides exceptionally good resistance to uniform corrosion combined with higher strength and mechanical properties than the more common austenitic grades.
UNS | AISI | Material No | Outokumpu | ASTM |
---|---|---|---|---|
S31254 | 904L | 1.4547 | 254SMO | A276 |
N08904 | 1.4539 | 6Mo (Moly) | A479 | |
EN10272 | B677 | |||
F44 |
Austenitic Stainless
With the average chromium content of 18% and nickel content of 8% austenitic stainless steels are sometimes referred to as 18/8 (although the actual chromium and nickel content can vary from these figures). Austenitic stainless steels are non magnetic and cannot be hardened by heat treatment, though they can strain harden rapidly when cold worked.
BS970 | AISI | Material No | DIN | UNS |
---|---|---|---|---|
316S11 | 310 | 1.4845 | X5CrNi18-10 | S31000 |
316S15 | 316L | 1.4541 | X5CrNi 18-10 | S31008 |
310S24 | 316 | 1.4571 | X8CrNiS18-9 | S32100 |
321S31 | 316Ti | 1.4301 | X8CrNiS18-9 | S30400 |
304S31 | 321 | 1.4305 | X2CrNi 19-11 | S30300 |
304S15 | 304 | 1.4306 | X6CrNiTi 18-10 | S30403 |
303S21 | 304L | 1.4307 | X12CrNi 25-21 | S30100 |
304S11 | 303 | 1.4310 | X6CrNiMoTi 17-12-2 | S31600 |
EN58E | 301 | 1.4539 | S31603 | |
EN58AM | 1.4404 | S31635 | ||
EN58M | ||||
EN58E | ||||
EN58B |
Martensitic Stainless
Heat treated martensitic stainless steel grades offer high strength and hardness. Martensitic grades can be heat treated due to having higher carbon content than other types of stainless steel. Martensitic grades are less ductile than other types of stainless steel. These grades are magnetic and are best suited for applications which require good corrosion resistance with good mechanical properties.
BS970 | AISI | Material No | DIN | UNS |
---|---|---|---|---|
416S21 | 440B | 1.4112 | X12CrS13 | S41000 |
410S21 | 440C | 1.4125 | X12Cr13 | S42000 |
420S29 | 420 | 1.4057 | X20Cr13 | S43100 |
420S37 | 410 | 1.4005 | X30Cr13 | S44003 |
420S45 | 416 | 1.4006 | X17CrNi16-2 | S44004 |
431S29 | 431 | 1.4021 | X90CrMoV18 | |
EN56AM | 1.4208 | X105CrMo17 | ||
EN56A | ||||
EN56C | ||||
EN56D | ||||
EN57 |
Duplex & Super Duplex Stainless
Duplex and Super Duplex stainless steel grades offer resistance to stress corrosion and crevice corrosion. They are higher strength grades than standard austenitic stainless steel specifications.
UNS | ASTM | Material No |
---|---|---|
S31083 | A182 | 1.4462 |
S32760 | F51 | 1.4501 |
F55 | EN10083 |
Heat Treatment
Heat treatment is only suitable for specific grades of stainless. When heat treating a stainless the hardening temperatures, including rate of heating, cooling and soaking times will vary due to factors such as the shape and size of each component. Other considerations during the heat treatment process include the type of furnace, quenching medium and work piece transfer facilities. Please consult your heat treatment provider for full guidance on heat treatment of stainless steel grades.
